CHRISTIE "Secure II SUHD653-L - 65"" Flat Panel 450 Nits" 4K UHD, L, 18h/7T, OPS Slot, Direct-lit

Bestell-Nr: C135-042107-01
CHF 4’280.00
Das Christie® SUHD653-L LCD-Panel ist ein TAA-konformes Nicht-RF-Display, das speziell für Anwendungen in sicheren Einrichtungen entwickelt wurde, wie sie typischerweise in Behörden, Unternehmen und militärischen Umgebungen zu finden sind. Das SUHD653-L ist ideal für Besprechungsräume, kleine Kontrollräume und Digital Signage-Anwendungen. Es vereint professionelle Funktionen wie OPS-Slot, Multi-Source-Anzeige und UHD-Auflösung in einem sicheren, zuverlässigen und erschwinglichen Paket.

Crestron Verbunden

Als Creston Connected-Gerät verfügt die Christie Secure Series über eine integrierte Crestron-Software, die eine nahtlose Anbindung an ein Crestron-Netzwerk gewährleistet. Dies ermöglicht die Überwachung, Verwaltung und Steuerung der Secure Series II-Panels über eine beliebige Webschnittstelle, einschließlich Desktops, Tablets und Mobilgeräte.

Wie alle Produkte von Christie wird auch die SUHD653-L von unserem branchenführenden Service und Support unterstützt, damit Sie sich darauf verlassen können.

Native resolution

4K UHD 3840 x 2160 (16:9)



Backlight

Edge-lit LED



LED lifespan

30,000 hours to 50% brightness



Display orientation

Landscape



Pixel pitch (WxH)

0.372 x 0.372mm



Bezel size (bottom/side/top)

19mm/19mm/19mm



Brightness (typical) - (cd/sq m)

450 nits



Contrast ratio (typical)

1,200:1



Viewing angle (CR 10:1)

178 degrees h/v



Refresh rate

60Hz



Response time (typical)

8ms



Color space typical (CIE 1931)

75%



Display colors

10 bit, 1.07 billion



Video inputs

  • 4 x HDMI (Ver 2.0b, HDCP 2.2)
  • DisplayPort Ver 1.2
  • OPS


Audio outputs

  • 3.5mm headphone jack


Control inputs

  • RS-232 via D-Sub9
  • LAN via RJ45
  • IR wire extender
  • USB-A2.0 for service


​​Power input rating

  • 100-240 VAC @ 50/60Hz
  •


Power consumption

  • 190W maximum without OPS
  • 0.5W standby without OPS


Operating temperature

  • 32-104°F (0-40°C)


Storage temperature

  • -4-140°F (-20-60°C)


Operating humidity

  • 20-90% RH non-condensing


​Physical size (panel only)

  • (WxHxD): 57.8 x 33.2 x 3.4" (1469 x 844 x 86mm)


Weight

  • 65lbs (29.5kg)


Mounting

  • TBD


Runtime

  • Recommended for 18/7 operation featuring a reliable power supply*
  •


Features

  • Commercial-grade LCD with LED backlight
  • OPS slot
  • Anti-glare treatment
  • 2 x 15W speakers
  • HDMI-CEC
  • DICOM simulation
  • HDR10 compatible
  • Priority Input Source
  • Source switching for failover
  • No RF capability
  • 4 window multi-source UHD viewing (Quadview, PiP, PBP)
  • MEMC
  • Crestron Connected 2


Accessories

  • Panel ships with HDMI 2.0 Cable, RS232 Cable, Remote Control with batteries, IR receiver


Warranty

  • Three years parts and labor limited warranty
  • Contact an authorized Christie® representative for full details of our limited warranty
