EspriTE PC - Wireless @Cardboard

| TE™ 650W Leuchtmittel | 33'000lm | Zoom 6°-60° | CMY+CTO (3000K-6700K) | 26kg
No. d'article: R10028222
DescriptionDonnées techniquesDownloads (5)
The ESPRITE PC offers you a dynamic, high performance wash light, whilst enjoying the many advantages of our TE™ Transferable Engine technology.
The ESPRITE PC features the low cost, transferable light engine, to ingeniously solve the problem of performance longevity and light consistency for those preferring the higher brightness of white source LEDs.
The self-referencing, data capturing TE™ 650W White LED engine, designed, developed and manufactured in our own factory, allows for rapid and economical “Lamp like” exchange to give both fixtures a life well beyond those of non-user replaceable LED sources.
Performance has not been compromised, with the ESPRITE PC producing over 33.000 lm with a more defined beam compared to the softer edge of the Fresnel.
The ESPRITE PC possesses a comprehensive feature set including: Flat field CMY mixing; variable CTO; remotely selectable CRI 70/80/90; two fast colour wheels; medium and light frosts; Scrim with graduated filter position control with +/- 180° rotation and edge colour correction for added finesse.
A quick, accurate internal barndoor provides individual blade control and +/- 90° module rotation, whilst a zoom range of 6 - 60° ensuring maximum flexibility.
Furthermore, these fixtures are enhanced by Cpulse™, the flicker free management system for the latest cameras; EMS™ for enhanced motion stability and L3™ Low Light Linearity dimming, for ultra-smooth fade to black allowing seamless integration with traditional lighting rigs.
Source
Light source type: TE™ 650W White LED TRANSFERABLE ENGINE
LED life expectancy: min. 50.000 hours
CRI: 70/80/90, remotely selectable
Colour temperature: 6.700K
Typical lumen maintenance: L70/B50 @ 50.000 hours
Light source warranty: 4 years or 20.000 hours
Optical system
Robe’s proprietary optical design
High - efficiency zoom optical system, ratio 10:1
Zoom range: 6° - 60°
High efficient component optics
Fixture total lumen output:
33.000 lm (in integrated sphere)
26.000 lm (on the wall)
Output lens diameter: 156 mm
Dynamic Effects
Cyan: 0 - 100%
Magenta: 0 - 100%
Yellow: 0 - 100%
Variable CTO: 3.000K - 6.700K
Colour Wheel 1: 5 fixed dichroic colours + white
Colour Wheel 2: 5 fixed dichroic colours + white
Internal barndoors: individual position control of 4 “doors”, +/- 90° module rotation (Patent pending)
Scrim: Graduated filter position control, +/- 180° module rotation (Patent pending)
Frost: variable light and medium
Motorized zoom and focus
Edge colour correction
Electronic strobe effect with variable speed up to 20 Hz
Pre-programmed random strobe & pulse effects
High resolution electronic dimming: 0 - 100%
L3™ - (Low Light Linearity) Imperceptible 18 bit dimming for ultra smooth fade to black
Cpulse™ special flicker free management for HD and UHD cameras, ready for 8K and 16K
AirLOC™ (Less Optical Cleaning) technology greatly reduces the level of airborne particles drawn over the optical elements. This increases the overall performance, light quality and time between routine cleaning and maintenance.
Control and programming
Setting & Addressing: ROBE Navigation System 2 (RNS2)
Display: QVGA Robe touch screen with battery backup, gravitation sensor for auto screen positioning, operation memory service log with RTC, stand-alone operation with 3 editable programs (each up to 100 steps), built-in analyser for easy fault finding
Protocols: USITT DMX-512, RDM, ArtNet, MA Net, MA Net2, sACN
Wireless CRMX™ technology from Lumen Radio: On request
DMX Protocol modes: 2
Control channels: 34, 30
Pan/Tilt resolution: 16 bit
CMY & CTO: 8 bit
Colour wheel positioning: 8 or 16 bit
Internal barndoor module movement & rotation: 8 bit
Edge colour correction
Frost: 8 bit
Zoom: 8 or 16 bit
Dimmer: 8 or 16 bit (internal 18 bit)
Movement
Pan movement: 540°
Tilt movement: 265°
Movement control: Standard and Speed
EMS™: Electronic Motion Stabilizer system for Pan & Tilt reducing beam deviation caused by truss movement or vibration (Patent pending)
Automatic Pan/Tilt position correction
Internal barndoors
Blades: 4 blades, each with separate movement control
Rotation: +/- 90° module rotation
Thermal specification
Maximum ambient temperature: 45°C (113°F)
Maximum surface temperature: 75°C (167°F)
Minimum operating temperature: -5°C (23°F)
Electrical specification and connections
Power supply: Electronic auto-ranging
Input voltage range: 100-240 V, 50/60 Hz
Power consumption: Standard mode max. 870 W at 230 V / 50 Hz
High-power mode max. 950 W at 230 V / 50 Hz
Power in connector: Neutrik powerCON TRUE1
DMX and RDM data in/out: Locking 3-pin & 5-pin XLR
Ethernet port in: RJ45
Approvals
CE Compliant
cETLus Compliant (pending)
Mechanical specification
Height: 719 mm (28.31")
Width: 443 mm (17.4")
Depth: 264 mm (10.4") - head in vertical position
Weight: 26 kg (57.3 lbs)
Ingress protection rating: IP20
Rigging
Mounting positions: Horizontally or vertically
Universal operating position
Mounting points: 5 pairs of 1/4-turn locking points
2x Omega adaptors with 1/4-turn quick locks
Safety cable attachment point
Pan and Tilt transport locks
Included items
User Manual
Omega Adaptor CL-regular 2 pcs
Power cord including powerCON TRUE1 In connector
Gel frame adaptor
